Ld systems MIX 10 A G3

Ref : 80801
- Product Type PA Speaker
- Active Type
- 10 "boomer diameter
- Boomer diameter 254 mm
- Custom made boomer brand
- Diameter tweeter 1 "
- Tweeter diameter (mm) 25.4 mm
- Brand tweeter Celestion
- Dispersion angle (H x V) 80 x 70 °
- Frequency response 65 - 20,000 Hz
- Class D amplifier
- Amplifier power (eff.) 2 x 200 W
- Amplifier power (peak) 2 x 400 W
- Maximum sound pressure level 124 dB
- Protection circuits Short-circuit, Limiter, Overload, Overvoltage.
Mix table
- Channels 7
- Micro inputs 3
- XLR 1/4 "microphone inputs, XLR
- DFX Send, EQ Hi, EQ Low, Level, Hi-Z (Channel 1 only) Mic Input Controls
- Line 2 inputs
- Line Input Connectors 2 x XLR, 3.5mm TRS
- Level Line Input Controls
- High impedance input (Hi-Z) 1
- High impedance input connector (Hi-Z) 6.35 mm jack
- High Impedance Input Impedance (Hi-Z) 1000 kohms
- Monitor Output, Line Level 2
- XLR Line Monitor Output Connector
- Monitor Line Outputs volume knob potentiometer, - - level control of the subwoofer
- Maximum Level of Monitor Output 17 dBu
- Number of Record 1 Outputs
- Main Output Power (Amplifier), 4 Ohm 200 W

Box
- Bass Reflex cabinet finish
- Material box 16 mm Plywood
- Surface of the box Painted structured paint
- Color black box
- Width 315 mm
- Height (mm) 489 mm
- Depth 307 mm
- Weight 12,3 kg
- Other Bluetooth properties, Ergonomic handle, Footwell with reclining device (0 ° / 5 °)
