Mobiele pa- systeem
The lD Systems MIX 10AG3 is a portable amplified speaker of 2x200 Watts.
The Mix 10AG3 incorporates a 7-channel mixer and Class D amplifier with 2 x 400 watts of power.
The compact bass-reflex speaker features a custom woofer and 1 "10" Celestion HF driver complement, frequency response from 65 Hz to 20 kHz and 90 ° x 60 ° dispersion.
Hosting a wide variety of input sources, including electronic instruments, smartphones, tablets, MP3 players and CDs, the built-in mixer provides 3-channel mic with 2-band EQ, 48 V phantom power.
The output section includes a 3-band master equalizer.
the LD 10 MIX A G3 incorporates a DSP with 16 effect presets, and overcurrent limiter, overload, short circuit and thermal protection.
A speakON output is used to power the passive LD MIX 10 G3 to easily create a stereo configuration.
Constructed of heavy duty plywood with a 50 ° control angle and a dual tilt pole receptacle for 0 ° or 5 ° mounting angles. Alone or in tandem with the passive unit, the LD MIX 10 G3 delivers exceptional performance and versatility in a lightweight, easy-to-carry package.
The Mix 10AG3 incorporates a 7-channel mixer and Class D amplifier with 2 x 400 watts of power.
The compact bass-reflex speaker features a custom woofer and 1 "10" Celestion HF driver complement, frequency response from 65 Hz to 20 kHz and 90 ° x 60 ° dispersion.
Hosting a wide variety of input sources, including electronic instruments, smartphones, tablets, MP3 players and CDs, the built-in mixer provides 3-channel mic with 2-band EQ, 48 V phantom power.
The output section includes a 3-band master equalizer.
the LD 10 MIX A G3 incorporates a DSP with 16 effect presets, and overcurrent limiter, overload, short circuit and thermal protection.
A speakON output is used to power the passive LD MIX 10 G3 to easily create a stereo configuration.
Constructed of heavy duty plywood with a 50 ° control angle and a dual tilt pole receptacle for 0 ° or 5 ° mounting angles. Alone or in tandem with the passive unit, the LD MIX 10 G3 delivers exceptional performance and versatility in a lightweight, easy-to-carry package.
Lire la suite
Technisch papier
- Product Type PA Speaker
- Active Type
- 10 "boomer diameter
- Boomer diameter 254 mm
- Custom made boomer brand
- Diameter tweeter 1 "
- Tweeter diameter (mm) 25.4 mm
- Brand tweeter Celestion
- Dispersion angle (H x V) 80 x 70 °
- Frequency response 65 - 20,000 Hz
- Class D amplifier
- Amplifier power (eff.) 2 x 200 W
- Amplifier power (peak) 2 x 400 W
- Maximum sound pressure level 124 dB
- Protection circuits Short-circuit, Limiter, Overload, Overvoltage.
- Mix table
- Channels 7
- Micro inputs 3
- XLR 1/4 "microphone inputs, XLR
- DFX Send, EQ Hi, EQ Low, Level, Hi-Z (Channel 1 only) Mic Input Controls
- Line 2 inputs
- Line Input Connectors 2 x XLR, 3.5mm TRS
- Level Line Input Controls
- High impedance input (Hi-Z) 1
- High impedance input connector (Hi-Z) 6.35 mm jack
- High Impedance Input Impedance (Hi-Z) 1000 kohms
- Monitor Output, Line Level 2
- XLR Line Monitor Output Connector
- Monitor Line Outputs volume knob potentiometer, - - level control of the subwoofer
- Maximum Level of Monitor Output 17 dBu
- Number of Record 1 Outputs
- Main Output Power (Amplifier), 4 Ohm 200 W
- Box
- Bass Reflex cabinet finish
- Material box 16 mm Plywood
- Surface of the box Painted structured paint
- Color black box
- Width 315 mm
- Height (mm) 489 mm
- Depth 307 mm
- Weight 12,3 kg
- Other Bluetooth properties, Ergonomic handle, Footwell with reclining device (0 ° / 5 °)
